AH D Transportation

Lorry Crane

65 Tones �V 225 Tones Crane Lorry
Basic Jib Long 15M �V 22M, Max Load 50 Tones
Added Extended to 41.9M, (Load 6 Tones)
(In addition, some models can be additionally equipped with Winch load 2.8T.)

35 Tones �V 50 Tones Crane Lorry
Basic Jib Long 16M �V 19.6M, Max Load 18 Tones
Added Extended to 29M, (Load 1.7 Tones)
(In addition, some models can be additionally equipped with Winch load 2.8T)

17 Tones �V 30 Tones Crane Lorry Basic Jib Long 11.9M �V 17M, Max Load 15.5 Tones

Grab-mount Lorry

All Grab-mounted Lorries equipped with auto-cover, blue-tooth electronic scale, rear-view mirror (Meet HKSAR Govern construction works requirement)

Normal 24T
Basic Jib Long 8.5M (2 Sections)
Optional Jib Long 10.5M (3 Sections)

Large 30T
Basic Jib Long 10.5M (3 Sections)
Optional Jib Long 12.5M (4 Sections)
Optional Jib Long 16M (6 Sections)

Extra Large 38T
Optional Jib Long 12.5M (4 Sections)

Flat Lorry

30Ton Flat Lorry
Maximum loading: ~15Ton

38Ton Flat Lorry
Maximum loading: ~24Ton

Tractor Trailer

Low Bed Trailer
Loading Platform Height: 700mm / 900mm / 1000mm

Extended Length Trailer
Loading Platform Height: 950mm
Overall Length: 16,380mm (Retracted) - 24,880mm (Extended)

Dump Truck

30Tones
Transporting mud, garbage, engineering, hardware scrap.

Street Sweeper

4 tons~9.5 tons. Hopper capacity : 3m3 ~ 4m3.

Articulated Dump Truck

BELL - B40E
Gross Power: 380 kW
Dump Capacity: 24 m?
Rated Payload: 39,000kg
Operating Weight: 70,787kg

BELL - B45E
Gross Power: 390 kW
Dump Capacity: 25 m?
Rated Payload: 41,000kg
Operating Weight: 72,877kg

VOLVO - A45G
Gross Power: 350 kW
Dump Capacity: 25.1 m?
Rated Payload: 41,000kg
Operating Weight: 71,000kg

DOOSAN - DA40
Gross Power: 368 kW
Dump Capacity: 26m? / 24.4m? (with/without tailgate)
Rated Payload: 40,000kg
Operating Weight: 70,300kg

20-30 Ton Excavator

20-30 ton Excavator

KOBELCO SK200
Operating Weight: 20,200kg
Bucket Capacity: 0.9m?

KOBELCO SK260
Operating Weight: 25,100kg
Bucket Capacity: 0.81m? - 1.20m?

KOBELCO SK350
Operating Weight: 35,200kg
Bucket Capacity: 1.20m? - 1.60m?

HITACHI ZX200
Operating Weight: 19,400kg
Bucket Capacity: 0.9m? - 1.0m?

30-50 Ton Excavator

VOLVO EC480DL
Operating Weight: 53,300kg
Bucket Capacity: 1.2m? �V 2.7m?

KOBELCO SK460
Operating Weight: 48,300kg
Bucket Capacity: 1.35m? - 3.40m?

DX340LC
Operating weight: 36,200kg
Bucket Capacity: 1.25m? �V 1.83 m?

DX530LC
Operating weight: 52,100kg
Bucket Capacity: 1.71m? �V 3.6 m?

Generator

All generators of our company have obtained high quality mobile equipment (QPME) and non-road mobile machinery (NRMMs) certification.

25kVA - 400kVA Generators
Our company's generator standby power output from 25 kVA to 400kVA, in line with various large, medium and small project projects, to meet environmental protection needs.

200A - Power Distribution Box
With 12 to 16(units) of 220V - 380V Output

Drilling Rig

DQ500
Technical Data
Recommended hole diameter: 45 - 89 mm (1 ? - 3 ? in.)
Drill rod / tube diameter: 32, 38, 45 mm (1 ?, 1 ?, 1 ? in.)
Hydraulic rock drill: HL 510, 15.5 kW (21 hp)
Engine type: Caterpillar C 7.1 Tier3 / Tier4F
Engine output power: 168 kW (228 hp) / 1,800 rpm
Flushing air capacity: 6.2 m?/min
Operator cabin: Ergo
Certificate: ROPS and FOPS
Transport Length: 7.2 / 10.7 m (23.6 / 35.1 ft)
Transport Width: 2.5 m (8.2 ft)
Transport Height: 3.6 / 3.2 m (11.8 /10.5 ft)
Weight: 15,400 kg (33,950 lb)

DX800
Technical Data
Recommended hole diameter: 76 - 127 mm (3 - 5 in.)
Drill rod / tube diameter: 45 or 51 mm (1 ? or 2 in.)
Hydraulic rock drill: HL820T, 21 kW / 28 hp, HF820T, 23 kW / 31 hp as option
Engine: Caterpillar C7.1, 168 kW (225 hp) / 1 800 rpm (Tier3 / Tier4F)
Flushing air capacity: 8.1 m?/min
Operator cabin: Ergo
Certificate: ROPS and FOPS
Transport Length: 7.2 m / 10.7 m (24 / 33 ft)
Transport Width: 2.45 m (8 ft)
Transport Height: 3.6 m / 3.2 m (12 / 11 ft)
Weight: 15,600 kg (33,510 lb)

Wheel Loader

Komatsu Wheel Loader-WA470
Operational :
Operating Weight: 23,370kg
Fuel Capacity: 390L
Operating Voltage: 24V
Rear Axle Oscillation: 30degrees
Dimensions :
Length with Bucket: 8,594 mm
Width Over Tires: 2,885 mm
Dump Clearance: 3,000 mm
Reach at Max Lift: 1,276 mm

Roller

Sany SSR200
Max. power: 148kW at rpm
Fuel tank capacity: 300L
Working weight: 20,800kg
Weight distribution per drum: 13,250kg
Axle weight distribution: 7,550kg
Static linear drum load: 610N / cm
Drum Width: 2,170mm
Drum Diameter: 1,600mm
Drum Rim Thickness: 40mm

Ammann ASC110
Max. Speed: 5.6 km/h
Fuel tank capacity: 410L
Working weight: 11,490kg
Static linear load: 34.5kg/cm
Drum Width: 2,130mm
Drum Diameter: 1,500mm
Drum Rim Thickness: 25mm
